DMX512/1990 Standard
Total of 192 output channels
30 banks have 8 programmable scenes each
16 slider for manual control of channels
Midi control over banks, chases and blackout
Record up to 6 programmable chases with fade time and speeds
LED function and program display
Midi control over banks, chases and blackout
Built in microphone for music trigerring
Auto mode program controlled by fade time sliders
DMX in/out: 3 pin male/female XRL
LED lamp connector
Power input: DC 9-12V 1000ma min
Dimensions(mm):520mmX183mmX73mm
Net Weight: 3.0kg
Technical features
6 programmable chase have 240 scenes each
