Source
Light source: Advanced 180W white led
Led life: 60.000 hours
Luminous Flux: 10985lumen, 21385lux@2.5m
Control: DMX512, Master/Slave, Auto, Sound
Ballast: switching mode power supply
Optical System
Beam angle: 15°
X/Y
Pan: 540°(2.3sec), Tilt: 265° (1.8 sec)
16-bit resolution
Auto repositioning
Colors
7+open, indexable and bidirectional rainbow effect
Gobos
Outside ¢25.5mm, inside ¢21.5mm
6+ open custom interchangeable position for rotating gobo wheel
8+ open fixed gobos
Real indexable and gobo shaking
Distinctive gobo animation effect
Features
DMX channels: 16CH
Color wheel: 7+1 colors
Fixed gobo wheel: 8+1 gobos
Rotating gobo wheel: 6+1 gobos
Motorized auto focus
Full range 0-100% dimmer
Various strobe
3-facets prism
Frost effect: 0-100% linear frost
Indicate temperature info of lamp
Fan speed auto change according to temperature
Power
Max power consumption: 250W
Powercon in and out
Power supply: Electronic auto-ranging
Input voltage range: 100–240V, 50-60Hz
Dimension and Weight
Fixture:275X245X353MM
Net Weight: 8.3KG
Gross Weight: 9.7KG
Rigging
Mounting points: 4 ¼-turn locks
2 x Omega brackets with ¼-turn quick locks
